Lithium Polymer battery, abbreviated as Li Po Battery, LiPo Battery,Li Poly Battery, LIP Battery, Li Polymer Battery, Lithium Poly Battery.
The LP804050 2P 3.7V 4000mAh 14.8Wh is a lipo battery pack, which uses a polymer electrolyte. As we all know, this new type battery now main uses in wearable devices, medical device, radio controlled equipment, personal electronics, and electric vehicles.
We are top lipo battery pack manufacturer in China, we produce and sell lipo batteries for more than 10 years. We can make rectangular lithium polymer battery, round lithium polymer battery, ultra-thin li poly battery, curved lithium polymer battery, cylindrical li polymer battery, RC li-po battery, and high discharge rate li poly battery. The LP804050 2P 3.7V 4000mAh 14.8Wh is one of our popular rechargeable lipo battery pack, buy some batteries for prototyping. Our MOQ is only 5 pieces, friendly to the small company.
Our rechargeable lipo battery pack with a protection circuit module(PCM), and two standard 100mm wires. It’s possible to add NTC, our NTC spec is 10KΩ 1% +25C B3380. If you need other connectors, it’s also possible, you can click below link to choose the JST/Molex connectors. https://www.lipobattery.us/select-connectors/
Battery Type: | Rechargeable LiPo Battery Pack |
Model: | LP804050, 804050 |
Nominal Voltage: | 3.7V |
Capacity: | 4000mAh |
Size: | 15.7mm x 39.9mm x 48.4mm |
Protection circuit module(PCM): | Yes |
Thermistor(NTC): | No |
Connector: | No |
Configuration: | 1S1P |
Weight: | 80g |
Wat-Hou Rating: | 14.8Wh |
Max. Operating Voltage Range: | 2.75V to 4.2V |
Max. Charge Voltage: | 4.2V±50mV |
Max. Charge Current: | 2000mA |
Max. Continuous Discharge Current: | 4000mA |
Discharge Cut-off | 2.75V |
Internal Impedance: | <200mΩ |
Expected Cycle Life @(0.5C/0.5C)@23±5°C) | 500 cycles ≥ 80% |
3.7V LiPo Battery LP105876 5300mAh 19.61Wh with PCM and wires and JST PHR-2
3.7V LiPo Battery LP105876 5300mAh 19.61Wh with PCM and wires and JST PHR-2 IEC62133/UN38.3/MSDS/RoHS certified lipo batteries 5000mAh+, small MOQ, get quotation sheet....
LiPo Battery LP704260 2P 3.7V 5000mAh 18.5Wh with protection circuit and wires 40mm and NTC and JST PHR-3
LiPo Battery LP704260 2P 3.7V 5000mAh 18.5Wh with protection circuit and wires 40mm and NTC and JST PHR-3 Are you looking for a business partner for lipo battery, we...
LiPo Battery LP685071 2P 3.7V 5700mAh 21.09Wh with protection circuit and wires 50mm and JST PHR-2
LiPo Battery LP685071 2P 3.7V 5700mAh 21.09Wh with protection circuit and wires 50mm and JST PHR-2 You can find a 5000mAh+ lipo battery for your new design. Get fast...
LiPo Battery LP626699 3.7V 5000mAh 18.5Wh without protection circuit, but with wires 50mm
LiPo Battery LP626699 3.7V 5000mAh 18.5Wh without protection circuit, but with wires 50mm Find the best lipo battery 5000mAh+ list with accurate size fit for different...
Li-Poly Battery LP124770 3.7V 5000mAh 18.5Wh with protection circuit and wires 50mm
Li-Poly Battery LP124770 3.7V 5000mAh 18.5Wh with protection circuit and wires 50mm Li-Poly battery pack with enough Inventory to fulfill the client’s order, get price...
Li Polymer Battery Pack LP4741122 2P 3.7V 5300mAh 19.61Wh with protection circuit and wires 50mm
Li Polymer Battery Pack LP4741122 2P 3.7V 5300mAh 19.61Wh with protection circuit and wires 50mm Our rechargeable li polymer battery pack easy to order, shop now. This...
Model | Capacity | L x W x T(mm) | Voltage |
---|---|---|---|
LP105068 | 4000mAh | 68 x 50 x 10 | 3.7V |
LP105274 | 4800mAh | 74 x 52 x 10 | 3.7V |
LP105472 | 4800mAh | 72 x 54 x 10 | 3.7V |
LP105561 | 4000mAh | 61 x 55 x 10 | 3.7V |
LP106065 | 4400mAh | 65 x 60 x 10 | 3.7V |
LP113488 | 4200mAh | 88 x 34 x 11 | 3.7V |
LP123079 | 4000mAh | 79 x 30 x 12 | 3.7V |
LP124273 | 4500mAh | 73 x 42 x 12 | 3.7V |
LP126386 | 4600mAh | 86 x 63 x 12 | 3.7V |
LP2510715 | 4500mAh | 715 x 10 x 2.5 | 3.7V |
LP2578143 | 4100mAh | 143 x 78 x 2.5 | 3.7V |
LP2583139 | 4850mAh | 139 x 83 x 2.5 | 3.7V |
LP2691121 | 4300mAh | 121 x 91 x 2.6 | 3.7V |
LP2763174 | 4300mAh | 174 x 63 x 2.7 | 3.7V |
LP28100110 | 4850mAh | 110 x 100 x 2.8 | 3.7V |
LP2884157 | 4000mAh | 157 x 84 x 2.8 | 3.7V |
LP2889142 | 4000mAh | 142 x 89 x 2.8 | 3.7V |
LP2974157 | 4300mAh | 157 x 74 x 2.9 | 3.7V |
LP2980159 | 4670mAh | 159 x 80 x 2.9 | 3.7V |
LP2984135 | 4000mAh | 135 x 84 x 2.9 | 3.7V |
LP2990135 | 4000mAh | 135 x 90 x 2.9 | 3.7V |
LP299114 | 4500mAh | 142 x 91 x 2.9 | 3.7V |
LP3072140 | 4400mAh | 140 x 72 x 3 | 3.7V |
LP3077149 | 4640mAh | 149 x 77 x 3 | 3.7V |
LP3080138 | 4100mAh | 138 x 80 x 3 | 3.7V |
LP3090135 | 4000mAh | 135 x 90 x 3 | 3.7V |
LP3263156 | 4000mAh | 156 x 63 x 3.2 | 3.7V |
LP3263158 | 4200mAh | 158 x 63 x 3.2 | 3.7V |
LP33100103 | 4000mAh | 103 x 100 x 3.3 | 3.7V |
LP331021 | 4500mAh | 102 x 108 x 3.3 | 3.7V |
LP3372138 | 4500mAh | 138 x 72 x 3.3 | 3.7V |
LP3457138 | 4300mAh | 138 x 57 x 3.4 | 3.7V |
LP3473131 | 4280mAh | 131 x 73 x 3.4 | 3.7V |
LP3480119 | 4000mAh | 119 x 80 x 3.4 | 3.7V |
LP3558145 | 4200mAh | 145 x 58 x 3.5 | 3.7V |
LP357412 | 4000mAh | 12 x 74 x 3.5 | 3.7V |
LP3580116 | 4000mAh | 116 x 80 x 3.5 | 3.7V |
LP3673102 | 4420mAh | 102 x 73 x 3.6 | 3.7V |
LP3790120 | 4500mAh | 120 x 90 x 3.7 | 3.7V |
LP386613 | 4050mAh | 130 x 66 x 3.8 | 3.7V |
LP395890 | 4000mAh | 90 x 58 x 3.9 | 3.7V |
LP3967114 | 4100mAh | 114 x 67 x 3.9 | 3.7V |
LP3970125 | 4000mAh | 125 x 70 x 3.9 | 3.7V |
LP3980110 | 4150mAh | 110 x 80 x 3.9 | 3.7V |
LP4054130 | 4560mAh | 130 x 54 x 4 | 3.7V |
LP4059134 | 4820mAh | 134 x 59 x 4 | 3.7V |
LP4059134 | 4840mAh | 134 x 59 x 4 | 3.7V |
LP4063134 | 4840mAh | 134 x 63 x 4 | 3.7V |
LP4068130 | 4200mAh | 130 x 68 x 4 | 3.7V |
LP4069124 | 4550mAh | 124 x 69 x 4 | 3.7V |
LP4080102 | 4000mAh | 102 x 80 x 4 | 3.7V |
LP4084100 | 4500mAh | 100 x 84 x 4 | 3.7V |
LP408710 | 4600mAh | 107 x 87 x 4 | 3.7V |
LP4153111 | 4000mAh | 111 x 53 x 4.1 | 3.7V |
LP4161132 | 4200mAh | 132 x 61 x 4.1 | 3.7V |
LP426385 | 4050mAh | 85 x 63 x 4.2 | 3.7V |
LP426783 | 4050mAh | 83 x 67 x 4.2 | 3.7V |
LP4271120 | 4500mAh | 120 x 71 x 4.2 | 3.7V |
LP427191 | 4500mAh | 91 x 71 x 4.2 | 3.7V |
LP436485 | 4050mAh | 85 x 64 x 4.3 | 3.7V |
LP436678 | 4040mAh | 78 x 66 x 4.3 | 3.7V |
LP4371104 | 4000mAh | 104 x 71 x 4.3 | 3.7V |
LP446088 | 4000mAh | 88 x 60 x 4.4 | 3.7V |
LP446484 | 4050mAh | 84 x 64 x 4.4 | 3.7V |
LP446580 | 4020mAh | 80 x 65 x 4.4 | 3.7V |
LP446598 | 4900mAh | 98 x 65 x 4.4 | 3.7V |
LP455595 | 4000mAh | 95 x 55 x 4.5 | 3.7V |
LP456579 | 4000mAh | 79 x 65 x 4.5 | 3.7V |
LP4568130 | 4250mAh | 130 x 68 x 4.5 | 3.7V |
LP456888 | 4020mAh | 88 x 68 x 4.5 | 3.7V |
LP466380 | 4000mAh | 80 x 63 x 4.6 | 3.7V |
LP466585 | 4200mAh | 85 x 65 x 4.6 | 3.7V |
LP466773 | 4140mAh | 73 x 67 x 4.6 | 3.7V |
LP466782 | 4125mAh | 82 x 67 x 4.6 | 3.7V |
LP475886 | 4000mAh | 86 x 58 x 4.7 | 3.7V |
LP476180 | 4030mAh | 80 x 61 x 4.7 | 3.7V |
LP476278 | 4040mAh | 78 x 62 x 4.7 | 3.7V |
LP476291 | 4050mAh | 91 x 62 x 4.7 | 3.7V |
LP476393 | 4530mAh | 93 x 63 x 4.7 | 3.7V |
LP477592 | 4700mAh | 92 x 75 x 4.7 | 3.7V |
LP478769 | 4830mAh | 69 x 87 x 4.7 | 3.7V |
LP478873 | 4780mAh | 73 x 88 x 4.7 | 3.7V |
LP4855112 | 4200mAh | 112 x 55 x 4.8 | 3.7V |
LP485985 | 4000mAh | 85 x 59 x 4.8 | 3.7V |
LP486180 | 4000mAh | 80 x 61 x 4.8 | 3.7V |
LP486586 | 4870mAh | 86 x 65 x 4.8 | 3.7V |
LP486789 | 4950mAh | 89 x 67 x 4.8 | 3.7V |
LP4868134 | 4000mAh | 134 x 68 x 4.8 | 3.7V |
LP496180 | 4000mAh | 80 x 61 x 4.9 | 3.7V |
LP496289 | 4870mAh | 89 x 62 x 4.9 | 3.7V |
LP496296 | 4850mAh | 96 x 62 x 4.9 | 3.7V |
LP496884 | 4950mAh | 84 x 68 x 4.9 | 3.7V |
LP5046145 | 4000mAh | 145 x 46 x 5 | 3.7V |
LP505196 | 4000mAh | 96 x 51 x 5 | 3.7V |
LP5058131 | 4000mAh | 131 x 58 x 5 | 3.7V |
LP506080 | 4000mAh | 80 x 60 x 5 | 3.7V |
LP506274 | 4000mAh | 74 x 62 x 5 | 3.7V |
LP506289 | 4840mAh | 89 x 62 x 5 | 3.7V |
LP506480 | 4400mAh | 80 x 64 x 5 | 3.7V |
LP5068132 | 4500mAh | 132 x 68 x 5 | 3.7V |
LP5158110 | 4200mAh | 110 x 58 x 5.1 | 3.7V |
LP516280 | 4000mAh | 80 x 62 x 5.1 | 3.7V |
LP516385 | 4300mAh | 85 x 63 x 5.1 | 3.7V |
LP517878 | 4328mAh | 78 x 78 x 5.1 | 3.7V |
LP517882 | 4400mAh | 82 x 78 x 5.1 | 3.7V |
LP5245114 | 4780mAh | 114 x 45 x 5.2 | 3.7V |
LP5264120 | 4900mAh | 120 x 64 x 5.2 | 3.7V |
LP526897 | 4300mAh | 97 x 68 x 5.2 | 3.7V |
LP527081 | 4205mAh | 81 x 70 x 5.2 | 3.7V |
LP527182 | 4205mAh | 82 x 71 x 5.2 | 3.7V |
LP528777 | 4400mAh | 77 x 87 x 5.2 | 3.7V |
LP536276 | 4000mAh | 76 x 62 x 5.3 | 3.7V |
LP5448106 | 4500mAh | 106 x 48 x 5.4 | 3.7V |
LP545688 | 4000mAh | 88 x 56 x 5.4 | 3.7V |
LP545792 | 4900mAh | 92 x 57 x 5.4 | 3.7V |
LP546089 | 4700mAh | 89 x 60 x 5.4 | 3.7V |
LP546171 | 4000mAh | 71 x 61 x 5.4 | 3.7V |
LP546791 | 4500mAh | 91 x 67 x 5.4 | 3.7V |
LP5548106 | 4440mAh | 106 x 48 x 5.5 | 3.7V |
LP5548135 | 4300mAh | 135 x 48 x 5.5 | 3.7V |
LP5559150 | 4000mAh | 150 x 59 x 5.5 | 3.7V |
LP5560110 | 4400mAh | 110 x 60 x 5.5 | 3.7V |
LP556676 | 4300mAh | 76 x 66 x 5.5 | 3.7V |
LP556787 | 4020mAh | 87 x 67 x 5.5 | 3.7V |
LP575577 | 4130mAh | 77 x 55 x 5.7 | 3.7V |
LP585488 | 4000mAh | 88 x 54 x 5.8 | 3.7V |
LP585677 | 4460mAh | 77 x 56 x 5.8 | 3.7V |
LP595490 | 4630mAh | 90 x 54 x 5.9 | 3.7V |
LP5959111 | 4650mAh | 111 x 59 x 5.9 | 3.7V |
LP596766 | 4010mAh | 66 x 67 x 5.9 | 3.7V |
LP605490 | 4600mAh | 90 x 54 x 6 | 3.7V |
LP606072 | 4500mAh | 72 x 60 x 6 | 3.7V |
LP606090 | 4000mAh | 90 x 60 x 6 | 3.7V |
LP606090 | 4050mAh | 90 x 60 x 6 | 3.7V |
LP606173 | 4650mAh | 73 x 61 x 6 | 3.7V |
LP606269 | 4000mAh | 69 x 62 x 6 | 3.7V |
LP6068135 | 4700mAh | 135 x 68 x 6 | 3.7V |
LP607777 | 4700mAh | 77 x 77 x 6 | 3.7V |
LP615490 | 4430mAh | 90 x 54 x 6.1 | 3.7V |
LP616484 | 4040mAh | 84 x 64 x 6.1 | 3.7V |
LP616665 | 4000mAh | 65 x 66 x 6.1 | 3.7V |
LP626263 | 4000mAh | 63 x 62 x 6.2 | 3.7V |
LP626798 | 4900mAh | 98 x 67 x 6.2 | 3.7V |
LP635777 | 4860mAh | 77 x 57 x 6.3 | 3.7V |
LP636468 | 4000mAh | 68 x 64 x 6.3 | 3.7V |
LP644690 | 4020mAh | 90 x 46 x 6.4 | 3.7V |
LP645465 | 4100mAh | 65 x 54 x 6.4 | 3.7V |
LP645482 | 4900mAh | 82 x 54 x 6.4 | 3.7V |
LP645892 | 4000mAh | 92 x 58 x 6.4 | 3.7V |
LP646064 | 4090mAh | 64 x 60 x 6.4 | 3.7V |
LP647464 | 4820mAh | 64 x 74 x 6.4 | 3.7V |
LP654190 | 4000mAh | 90 x 41 x 6.5 | 3.7V |
LP656090 | 4300mAh | 90 x 60 x 6.5 | 3.7V |
LP656280 | 4500mAh | 80 x 62 x 6.5 | 3.7V |
LP656678 | 4000mAh | 78 x 66 x 6.5 | 3.7V |
LP664878 | 4040mAh | 78 x 48 x 6.6 | 3.7V |
LP665775 | 4100mAh | 75 x 57 x 6.6 | 3.7V |
LP675268 | 4000mAh | 68 x 52 x 6.7 | 3.7V |
LP676069 | 4400mAh | 69 x 60 x 6.7 | 3.7V |
LP6846112 | 4500mAh | 112 x 46 x 6.8 | 3.7V |
LP695969 | 4000mAh | 69 x 59 x 6.9 | 3.7V |
LP7045148 | 4600mAh | 148 x 45 x 7 | 3.7V |
LP7052114 | 4500mAh | 114 x 52 x 7 | 3.7V |
LP705891 | 4700mAh | 91 x 58 x 7 | 3.7V |
LP706095 | 4670mAh | 95 x 60 x 7 | 3.7V |
LP706875 | 4100mAh | 75 x 68 x 7 | 3.7V |
LP724889 | 4000mAh | 89 x 48 x 7.2 | 3.7V |
LP7555103 | 4500mAh | 103 x 55 x 7.5 | 3.7V |
LP755585 | 4000mAh | 85 x 55 x 7.5 | 3.7V |
LP755595 | 4800mAh | 95 x 55 x 7.5 | 3.7V |
LP756085 | 4240mAh | 85 x 60 x 7.5 | 3.7V |
LP756161 | 4200mAh | 61 x 61 x 7.5 | 3.7V |
LP765965 | 4850mAh | 65 x 59 x 7.6 | 3.7V |
LP766569 | 4200mAh | 69 x 65 x 7.6 | 3.7V |
LP785588 | 4600mAh | 88 x 55 x 7.8 | 3.7V |
LP805097 | 4500mAh | 97 x 50 x 8 | 3.7V |
LP805187 | 4000mAh | 87 x 51 x 8 | 3.7V |
LP805290 | 4450mAh | 90 x 52 x 8 | 3.7V |
LP807070 | 4000mAh | 70 x 70 x 8 | 3.7V |
LP814695 | 4815mAh | 95 x 46 x 8.1 | 3.7V |
LP824982 | 4000mAh | 82 x 49 x 8.2 | 3.7V |
LP835876 | 4800mAh | 76 x 58 x 8.3 | 3.7V |
LP844294 | 4000mAh | 94 x 42 x 8.4 | 3.7V |
LP854294 | 4000mAh | 94 x 42 x 8.5 | 3.7V |
LP854685 | 4000mAh | 85 x 46 x 8.5 | 3.7V |
LP856078 | 4850mAh | 78 x 60 x 8.5 | 3.7V |
LP865181 | 4400mAh | 81 x 51 x 8.6 | 3.7V |
LP885890 | 4800mAh | 90 x 58 x 8.8 | 3.7V |
LP906667 | 4400mAh | 67 x 66 x 9 | 3.7V |
LP924981 | 4500mAh | 81 x 49 x 9.2 | 3.7V |
LP935070 | 4000mAh | 70 x 50 x 9.3 | 3.7V |
LP944277 | 4030mAh | 77 x 42 x 9.4 | 3.7V |
LP954673 | 4000mAh | 73 x 46 x 9.5 | 3.7V |
LP954878 | 4000mAh | 78 x 48 x 9.5 | 3.7V |
LP955266 | 4000mAh | 66 x 52 x 9.5 | 3.7V |
LP974673 | 4000mAh | 73 x 46 x 9.7 | 3.7V |

2600mAh Lithium ion Battery LP18650C Application to Book Scanner
LiPo Battery Applications 2600mAh Lithium ion Battery LP18650C Application to Book Scanner This is the fasted book scanner built-in LP18650C 2600mah lithium ion rechargeable battery in the world, discover the different use of the book scanner. This compact and...

3500mAh Li-ion Battery LP18650A+ Application to Smart Pet Feeder
LiPo Battery Applications 3500mAh Li-ion Battery LP18650A+ Application to Smart Pet Feeder If you have a pet, you will know to feed them is a very complex thing. Sometimes you are out of the home, some pets have medical conditions that need regular meals. This smart...

2000mAh LiPo Battery LP634860 Application to Baby Monitor
LiPo Battery Applications 2000mAh LiPo Battery LP634860 Application to Baby Monitor This wireless baby video monitor, the reason why it can realize wireless video monitoring is related to its built-in 2000mAh LP634860 lipo battery. 2000mAh large capacity wireless...
3.7V LiPo Battery Pack LP804050 2P 3.7V 4000mAh 14.8Wh with protection circuit and wires 100mm
LiPo Battery Pack For Sell, China Top Manufacturer, Extensive Inventory, Premium Quality, Cost-effective for your Applications. Immediate access to deep Inventory Now. This LiPo Battery Pack LP804050 3.7V 4000mAh, the size is 15.7mm x 39.9mm x 48.4mm, and the battery with protection circuit module and wires 100mm. For small samples, the MOQ is 5 pieces, we have the ability to produce mass production of LiPo Battery Pack. Also, we provide customized services, in any shape and size, you can custom your own LiPo Battery Pack.
If you want a completed quotation or a datasheet, please contact us.
